FEATURES
Varde 12PF is a compact, low profile, coaxial, 12" two-way full-range monitor series speaker with different configurations, has balanced and real sound quality. Configuration: 1 x 12" high-efficiency mid-bass unit and 1 x 1" exit throat 44mm voice coil HF driver with specially designed horn.The cabinet is made of multi-layer composite plywood with wear-resistant polyurea paint. The model Varde 12PN has a neodymium magnet unit.
TECHNICAL SPECIFICATIONS
- TECHNICAL SPECIFICATIONS
-
FREQUENCY RESPONSE
75Hz-18kHz
-
DRIVERS
1x12"(300mm)/3"voice coil LF1x1"(25mm)/1.7"voice coil HF
-
RATED POWER
300W RMS, 1200W peak
-
SENSITIVITY
97dB 1watt/1 meter
-
MAXIMUM SPL
122 dB continuous, 128 dB peak
-
IMPEDANCE
8 ohms nominal
-
DISPERSION(-6dB)
70°x40°
-
CROSSOVER FREQUENCIES
2.3kHz passive
-
INPUT CONNECTORS
2xSpeakon NL4
-
DIMENSIONS
(W)450mm x (H)330mm x (D)465mm
-
NET WEIGHT
24kg/pc
