FEATURES
Odense 406PN,a two-way column speaker with different configurations of mid-woofers and high-frequency units, brings together high sensitivity with clear and bright sonic characteristics.
lt is equipped with 4 x 6-inch neodymium mid-woofers and 2 x 1-inch exit-throat 44mm neodymium high-frequency drivers, which, togetherwith the line-array horn,optimize sound coverage and clarity.
Operated with the Odense 15ASUB subwoofer, expanding it into acomplete sound system that adapts to the audio needs of a widerange of small to medium-sized venues.
TECHNICAL SPECIFICATIONS
- TECHNICAL SPECIFICATIONS
-
FREQUENCY RESPONSE
80Hz-18kHz
-
DRIVERS
4x6"(150mm)/1.5"voice coil LF2x1"(25mm)/1.7"voice coil HF
-
RATED POWER
320W RMS, 1280W peak
-
SENSITIVITY
98dB 1watt/1 meter
-
MAXIMUM SPL
123 dB continuous, 129 dB peak
-
IMPEDANCE
8 ohms nominal
-
DISPERSION(-6dB)
110°x25°(-17.5°/+7.5°)
-
CROSSOVER FREQUENCIES
2.5kHz passive
-
INPUT CONNECTORS
2xSpeakon NL4
-
DIMENSIONS
(W)158mm x (H)242mm x (D)1290mm
-
NET WEIGHT
16kg/pc
Accessories

WALL BRACKET (2)
