FEATURES
Odense 803PN, a high-performance full-range column speaker, is characterized by its compact size, light weight, high sensitivity, and bright and clear sound quality. lt supports stand-alone operation or synergizes with the Odense 12ASUB subwoofer to build a sound system that adapts to different small and medium-sized venues.
Odense 803PN is equipped with 8 x 3-inch neodymium-iron-boron full-range units to ensure even sound distribution and high-fidelity output. The cabinet is made of aluminum alloy, providing excellent corrosion resistance and structural stability.
TECHNICAL SPECIFICATIONS
- TECHNICAL SPECIFICATIONS
-
FREQUENCY RESPONSE
125Hz-18kHz
-
DRIVERS
8x3"Neo/0.8"voice coil LF1x1"Neo/1"voice coil HF
-
RATED POWER
200W RMS, 800W peak
-
SENSITIVITY
97dB 1watt/1 meter
-
MAXIMUM SPL
120 dB continuous, 126 dB peak
-
IMPEDANCE
8 ohms nominal
-
DISPERSION(-6dB)
120°x30°
-
CROSSOVER FREQUENCIES
2.9kHz passive
-
INPUT CONNECTORS
2xSpeakon NL4
-
DIMENSIONS
(W)95mm x (H)885mm x (D)108mm
-
NET WEIGHT
6kg/pc
Accessories

Flexible Pole

WALL BRACKET (7)
