FEATURES
Odense 12ASUB, a single 12-inch subwoofer, features a bass-reflex design with a customized woofer that delivers deep and powerful low-frequency response.The configuration includes 1 x 12-inch 75mm high-efficiency woofer to ensure mellow and powerful sound quality.
The cabinet structure is constructed of multi-layer composite plywood with an abrasion-resistant polyurea finish for enhanced durability and protection. As an active system, Odense 12ASUB has a built-in dual-channel digitalamplifier, featuring full-band and sub-band outputs, providing flexibility.expandability and control of the audio system.
Odense 12ASUB paired with the Odense 803PN to meet the audio needs of small to medium-sized venues.
TECHNICAL SPECIFICATIONS
- TECHNICAL SPECIFICATIONS
-
FREQUENCY RESPONSE
LF: 45Hz-250HzSystem: 45Hz-18kHz
- DRIVERS
1x12"/3"voice coil LF- RATED POWER
1500W/8Ω+450W/8Ω- MAXIMUM SPL
121 dB continuous, 127 dB peak- INPUT CONNECTORS
XLR- DIMENSIONS
(W)325mm x (H)535mm x (D)515mm- NET WEIGHT
26kg/pc - DRIVERS
